Two Dimensional Industrial Mixing Machine 1.1kw SYH For Medicine

Name: Two Dimensional Industrial Mixing Machine 1.1kw SYH For Medicine
Brand: EYH Two Dimensional Mixer
SKU: EYH
Price: 5 USD
Availability: InStock
Rating: 5 (127 reviews)

Product Details

Place of Origin: china

Brand Name: EYH Two Dimensional Mixer

Certification: CE, ISO 9001: 2008, ISO 10004

Model Number: EYH

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: 5,000 USD to 30,000 USD

Packaging Details: Wooden Case + Plastic Film

Delivery Time: 7-15Working Days

Payment Terms: L/C , D/A , D/P , T/T , Western Union , MoneyGram

Supply Ability: 30Sets/Months

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Industrial Mixing Machine 1.1kw, 1.1kw Medicine Mixing Machine, SYH Medicine Mixing Machine


Type:	EYH Two Dimension Mixer	Application:	Medicine , Food , Feed , Fertilizer , Etc .
Condition:	New	Place Of Origin:	China
Brand Name:	Senmao	Voltage:	Customize
Power(kw):	2-30	Dimension(LWH):	Variable
Key Selling Points:	The Material Is Fully Mixed In A Short Time	Warranty:	1years
Weight(Ton):	Variable	Applicable Industries:	Medicine , Industry , Chemical Industry , Etc .
Machinery Test Report:	Provided	Video Outging Inspection:	Provided
Warranty To Core Components:	1Year	Mateial:	SUS304,SUS316L
Product Name:	SZG Series Conical Vacuum Dryer	Delivery:	45-90days
Guarantee Period:	1year	Package:	Wooden Case

Type:	EYH Two Dimension Mixer
Application:	Medicine , Food , Feed , Fertilizer , Etc .
Condition:	New
Place Of Origin:	China
Brand Name:	Senmao
Voltage:	Customize
Power(kw):	2-30
Dimension(LWH):	Variable
Key Selling Points:	The Material Is Fully Mixed In A Short Time
Warranty:	1years
Weight(Ton):	Variable
Applicable Industries:	Medicine , Industry , Chemical Industry , Etc .
Machinery Test Report:	Provided
Video Outging Inspection:	Provided
Warranty To Core Components:	1Year
Mateial:	SUS304,SUS316L
Product Name:	SZG Series Conical Vacuum Dryer
Delivery:	45-90days
Guarantee Period:	1year
Package:	Wooden Case

Two Dimensional Industrial Mixing Machine 1.1kw SYH For Medicine

Two Dimensional Mixer For Medicine , Food Material Mixing , Chemical Material Mixing

Products Descriptions
Raw material moves in two direction in the chamber, include swaying move and rotary move. Two directions moving forces raw material blended completely.

Because of simpler mixing principle and structure, volume of EYH could be much bigger.

SYH is suitable for mixing powder form or granule form solid raw material.

Products Principle
The two-dimensional motion mixer is mainly composed of three parts: the rotating frame, the swing frame and the frame. The drum is mounted on the swing frame, supported by four rollers and positioned axially by two stop wheels. Among the four supporting rollers, two of the transmission wheels are driven by the rotating power system to make the rotating drum rotate; the swing frame is driven by a set of crank-swing-rod mechanisms, which are mounted on the frame, and the swing frame is driven by bearings Components are supported on the rack.

Products Parameters

Model

Volume (L)

Loading volume (L)

Feeding amount

(kg)

Overall size

(mm)

Power]

(Kw)

Rotary motor

Swaying motor

EYH100

100

860

900

200

400

1000

1500

1.1

0.75

EYH300

300

150

1000

1100

200

580

1400

1650

1.1

0.75

EYH600

600

300

150

1300

1250

240

720

1800

1850

1.5

1.1

EYH800

800

400

200

1400

1350

240

810

1970

2100

1.5

1.1

EYH1000

1000

500

350

1500

1390

240

850

2040

2180

2.2

1.5

EYH1500

1500

750

550

1800

1550

240

980

2340

2280

1.5

EYH2000

2000

1000

750

2000

1670

240

1100

2540

2440

2.2

EYH2500

2500

1250

950

2200

1850

240

1160

2760

2600

2.2

EYH3000

3000

1500

1100

2400

1910

280

1220

2960

2640

EYH5000

5000

2500

1800

2700

2290

300

1440

3530

3000

7.5

EYH10000

10000

5000

3000

3200

2700

360

1800

4240

4000

EYH12000

12000

6000

4000

3400

2800

360

1910

4860

4200

EYH15000

15000

7500

5000

3500

3000

360

2100

5000

4400

18.5

Details Image
Two Dimensional Industrial Mixing Machine 1.1kw SYH For Medicine 0

Two Dimensional Industrial Mixing Machine 1.1kw SYH For Medicine 2
