Pharmaceutical Sodium Chloride Pill Making Mannitol Spherical Shot Blasting Machine

Product Details

Place of Origin: China

Brand Name: Ball shot blasting machine

Model Number: QZL

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 1,200 USD to 15,000 USD

Packaging Details: wooden box

Delivery Time: 48working days

Payment Terms: L/C, T/T

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                Mannitol Spherical Shot Blasting Machine, Sodium Chloride Pill Making Machine, Hot Air Circulation Oven dryer


Model:	QZL-100	Drying Medium:	Air
Heating Method:	Conductive	Applicable Materials:	Various Available
Temperature Range:	Low Temperature Type	Application Areas:	Pharmaceutical, Chemical And Food

Model:	QZL-100
Drying Medium:	Air
Heating Method:	Conductive
Applicable Materials:	Various Available
Temperature Range:	Low Temperature Type
Application Areas:	Pharmaceutical, Chemical And Food

Pharmaceutical Sodium Chloride Pill Making Mannitol Spherical Shot Blasting Machine

Description

It is used for the molding of pellets, and is also suitable for the preparation of membrane-controlled and skeleton-type slow and controlled pellets. It is an ideal equipment for making pellets in the pharmaceutical, food and chemical industries. Through the specially designed rotor structure, this machine can process various wet granules into beautiful spherical granules. It is an equipment for preparing capsules and traditional Chinese medicine pills.

Features
This machine is equipped with a rotating centrifugal disk, a blower, and a pneumatic spray gun to turn wet particles into beautiful pellets. Put the wet particles made in the previous process into the rotating centrifugal disc, start the blower and then start the rotating centrifugal disc, so that the wet particles are affected by the buoyancy of the annular air, the rotating centrifugal force and their own gravity, and move in a circumferential rope-like manner. Forms pellets with true sphericity*.

Technical Parameters

型号	QZL-350	QZL-600	QZL-1000
生产能力(kg/h)	20-100	80-500	500-1200
颗粒大小(mm)	Φ0.5-Φ5	Φ0.5-Φ5	Φ0.5-Φ5
转盘直径(mm)	350	600	1000
转盘转速(rpm)	200-600	200-600	200-600
总功率(kw)	2.2	3.0	5.5
外形尺寸 (长×宽×高)(mm)	1100×700×1320	1500×1200×1500	1800×1350×1650
重量(kg)	232	350	450

Pharmaceutical Sodium Chloride Pill Making Mannitol Spherical Shot Blasting Machine 0
